Positive Grid Spark Cab 140w Powered Amplifier 1x10 Cabinet Black

140-Watt powered guitar amp speaker cabinet optimized to work seamlessly with Spark 40, Spark MINI, and Spark GO amps, as well as any other instrument or amp with a line level out. Versatile, high-quality sound for live performances, recording sessions, and home practice.

Spark CAB is designed to provide a high-quality and versatile amplification solution for the Positive Grid Spark 40, Spark MINI, and Spark GO amps (it can also be an extension cab for Spark Live), as well as other guitar amps and digital modeling systems. With its high-quality sound, powerful amplification, versatile connectivity, and custom-designed compatibility with Positive Grid Spark amps, the Spark Cab is set to become a popular choice among guitar players who perform live and/or need to be louder.

● 140 Watt Class D powered FRFR cabinet
● Especially designed and optimized for Spark Series amps
● Transform your Spark 40, MINI, or GO into stage ready amps
● Looks cool/perfect match for your Spark amp and is fairly compact
● More features than a traditional guitar cab
● Compact, loud, and expandable by chaining multiple Spark CABs together
● Compatible with other modelers, processor, and amps

AUDIO SPECIFICATIONS
FREQUENCY RANGE
45-20,000 Hz
STEREO/MONO
MONO

MAXIMUM SOUND PRESSURE LEVEL
117 dB (RMS), 120 dB (Peak)

CABINET PRINCIPLE
Bass Reflex

POWER AMPLIFIERS
140 Watt Class D Amplifier

SPEAKERS
1x10-inch woofer, 2x1-inch (25mm) tweeter

TOTAL IMPEDANCE
4 ohms

CONTROLS AND CONNECTIVITY
BACK PANEL CONTROLS
Input Selector - Switch between the 3.5 mm Spark Input and the two mono XLR/TRS Combo Inputs
Speaker Volume
Line Out Volume
Ground Lift Switch
Contour Switch - Boosts low and high frequencies to improve balance at low volumes

WIRED CONNECTIVITY
1 x 1/8" dedicated stereo Input for Spark Amp
2 x mono XLR/TRS combo inputs
1 x mono XLR balanced output

PHYSICAL UNIT
DIMENSIONS
492.5 x 399.8 x 255 mm (with rubber feet) (19.39 x 15.74 x 10.04 in)

WEIGHT
13.5 kg
29.76 lbs

GRILLE CLOTH
Woven

Handle
2 recessed speaker handles on the sides

Cable Tie
1 adjustable cable tie for fixing instrument and audio cables on the back

POWER

MAIN INPUT POWER
AC 100-240V

DC POWER OUTPUT For Spark
DC 19V/2.5A

USB-C POWER OUTPUT For Spark MINI & GO
DC 5V/2A
